Glass Door Merchandiser Freezers

Q: How cold does a merchandiser freezer get?

Ours run from -10F up to 10F. That range covers packaged frozen product of every kind - retail bags, boxes, novelties, frozen meals. What it does not cover is ice cream you intend to scoop, which needs to sit around -8F to -4F and be served out of a cabinet that opens to the operator rather than the customer. Set the cabinet at the cold end of its range if you are holding ice cream for sale in the tub.

Q: What is the difference between a merchandiser freezer and a display freezer?

They overlap. Display freezer is the general term for any freezer built to show product to a customer, chest cabinets included. Merchandiser freezer almost always means the upright glass door version specifically. The practical difference between the two formats is floor efficiency and access: an upright holds about two and a half times as much per square foot and is shopped at eye level; a chest is shopped by looking down into it and is hard to beat in an impulse position near the register.

(33 products)

Upright glass door merchandiser freezers for frozen grocery, novelties and grab-and-go — one to three doors, 12 to 72 cu ft, LED lit, on R290. These hold −10°F to 10°F, which is a wider band than a dedicated ice cream freezer, so check the guide below before you buy one for scoopable product.

Glass Door Merchandiser Freezer Buying Guide

An upright glass door freezer sells frozen product the way a cooler sells drinks: the customer reads the shelf through the door, opens it, takes one. It runs from -10°F up to 10°F, which covers packaged frozen goods of every kind, and it holds more product per square foot of floor than any other display freezer format.

Why uprights win on floor space

A chest cabinet buys capacity with floor; an upright buys it with height, and floor is the expensive one. The comparison inside our own range:

PLM-HGD23F — 26 3/4" wide × 31 7/8" deep = 5.9 sq ft of floor for 23 cu ft, or 3.9 cu ft per square foot.
A 71" chest display freezer — 13.8 sq ft of floor for 20 cu ft, or 1.45 cu ft per square foot.

Roughly two and a half times the product in the same footprint, at eye level, behind glass a customer reads without opening anything. That is the whole case for the format.

The Polarman merchandiser freezer line

Swing glass doors, LED interior lighting, bottom-mounted compressor, R290.

Model	Doors	Width	Depth	Height	Capacity	Cu ft per sq ft of floor	Electrical	Weight
PLM-HGD12F	1	25"	26"	61 13/16"	12 cu ft	2.66	115 V / 5 A	258 lb
PLM-HGD16F	1	25"	26"	74 13/16"	16 cu ft	3.55	115 V / 5 A	289 lb
PLM-HGD23F	1	26 3/4"	31 7/8"	79 1/2"	23 cu ft	3.88	115 V / 8 A	353 lb
PLM-HGD48F	2	53 15/16"	31 7/8"	83 7/10"	48 cu ft	4.02	115 V / 9 A	567 lb
PLM-HGD72FDV	3	81"	31 7/8"	83 7/10"	72 cu ft	4.02	220 V / 9 A	829 lb

Two numbers worth stopping on

HGD12F to HGD16F is free capacity. Identical 25" × 26" footprint, identical 5 A draw — 13 more inches of height buys 33% more product. Unless a shelf, soffit or sight line caps the height, the 16 cu ft cabinet is the one to take.
The three-door unit is 220 V. The PLM-HGD72FDV needs a 220 V supply where the rest of the line runs on ordinary 115 V. That is an electrician's job, booked before the truck arrives — not something to discover on delivery day.

Before you order

Measure the route in, not just the spot. The two- and three-door cabinets stand 83 7/10" tall and the widest is 81", at 829 lb. Doorways, corners and lifts all need checking first.
Check the ceiling and any soffit. At 83 7/10" these cabinets want real clearance above for the compressor to shed heat.
Keep the base clear. The compressor draws air low at the front. Stock or pallets against the grille are the usual cause of a cabinet that holds overnight and drifts warm by afternoon.
Do not use one for scoopable ice cream. At the warm end of its range this cabinet runs at 10°F, which is right for packaged goods and too warm to portion out of. For that, go to a dipping cabinet.

Glass door merchandiser freezer FAQ

How cold does a merchandiser freezer get?

Ours run from -10°F up to 10°F. That range covers packaged frozen product of every kind — retail bags, boxes, novelties, frozen meals. What it does not cover is ice cream you intend to scoop, which needs to sit around -8°F to -4°F and be served out of a cabinet that opens to the operator rather than the customer. Set the cabinet at the cold end of its range if you are holding ice cream for sale in the tub.

Glass door or solid door?

Glass when the cabinet is on the sales floor and the product is the advertisement; solid when it is a back-of-house storage freezer nobody shops from. A solid door insulates better and costs less to run, so there is no reason to pay for glass on a walk-in-adjacent storage unit. On the sales floor the maths flips: a customer who can read the shelf without opening the door buys more and holds the door open less.

What is the difference between a merchandiser freezer and a display freezer?

They overlap. "Display freezer" is the general term for any freezer built to show product to a customer, chest cabinets included. "Merchandiser freezer" almost always means the upright glass door version specifically. The practical difference between the two formats is floor efficiency and access: an upright holds about two and a half times as much per square foot and is shopped at eye level; a chest is shopped by looking down into it and is hard to beat in an impulse position near the register.

What size merchandiser freezer should I buy?

Work from the wall you have and then check what each inch buys, because the line is not linear. The biggest single jump is the cheapest: our 12 cu ft and 16 cu ft cabinets share an identical 25 by 26 inch footprint and an identical 5 A draw, so 13 inches of extra height adds 33% more capacity for no floor at all. Above that, the two- and three-door cabinets are the most floor-efficient in the range at just over 4 cu ft per square foot.

What electrical supply do these need?

Most of the line is 115 V single phase, drawing 5 A on the single-door cabinets, 8 A at 23 cu ft and 9 A on the two-door. The exception matters: the three-door PLM-HGD72FDV is 220 V. If that is the cabinet you want, book the electrician before the delivery is scheduled, because a 220 V outlet is wall work and not something anyone sorts out on the morning the truck arrives.

How much clearance does an upright freezer need?

Check the model page for the figure, and treat two things as non-negotiable: clear air above the cabinet, and a clear base at the front. These use bottom-mounted compressors that draw air low and shed heat in the same area, so a cabinet with stock stacked against the grille or squeezed under a tight soffit will hold temperature overnight and drift warm through the trading day. Our tallest cabinets stand 83 7/10 inches, so a low soffit is a real constraint, not a detail.

Can I put one in an unheated stockroom or garage?

Talk to us about the location first. Commercial refrigeration is rated for an ambient range, and a space that swings cold in winter or hot in summer can push a cabinet outside it in both directions — a freezer in a cold room can actually run worse, not better, because the thermostat stops calling and the cabinet stops cycling normally. Tell us the room and we will confirm whether the model you are looking at suits it.
